DM PLANT MANUFACTURERS IN HYDERABAD

Name: DM PLANT MANUFACTURERS IN HYDERABAD
Brand: AMR Infinite Technologies
Price: 575000 INR
Availability: InStock

DM PLANT MANUFACTURERS IN HYDERABAD Specification

Power Consumption
1-3 Kilowatt (kW)

Feature
Corrosion Resistant, Robust Design, Easy Installation, High Efficiency

Ph Level
6.5 - 7.5

Frequency
50 Hertz (HZ)

Recycle Rate
95% approx.

Technology
Ion Exchange

Water in conductivity
Up to 2000 S/cm

Water Out Conductivity
Less than 0.1 S/cm

Usage & Applications
Boiler Feed, Pharmaceutical, Power Plant, Laboratory, Chemical Processing

Flow Rate
As per requirement (500 LPH - 100,000 LPH)

Pump Type
Centrifugal Pump

Efficiency (%)
up to 98%

Noise Level
70 db

Voltage
220-240V Volt (v)

Product Type
Demineralization (DM) Plant

Water Source
Borewell water, municipal water, ground water, process water

Purity Level
Up to 99.9%

Automatic Grade
Automatic, Semi-Automatic

Power Source
Electric

Drive Type
Electric Motor Driven

Material
FRP, Mild Steel with FRP lining, Stainless Steel

Filter Type
Multi-Grade Filter, Carbon Filter

Installation Type
Skid Mounted/Containerized/On-site

Ambient Operating Temperature
Up to 50°C

Regeneration Method
Co-current/Counter-current

Service Life of Resin
2-3 years (depending on usage)

Outlet Water Quality
TDS < 1 ppm, Silica < 0.01 ppm

Control System
PLC Based/Manual

Inlet Temperature
5°C - 45°C

Resin Type
Strong Acid Cation, Strong Base Anion

Pre Filtration Requirement
Yes (Sand Filter/Activated Carbon Filter)

Certificates
ISO 9001:2015 Certified

Disinfection System
UV/Sodium Hypochlorite (optional)

Operation Mode
Continuous/Batch

Connection Type
Flanged/Threaded

Painting/Coating
Epoxy/PU Coated for corrosion resistance

Design Pressure
2-4 kg/cm²

Sample Valve
Provided

DM PLANT MANUFACTURERS IN HYDERABAD Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
7 Days

About DM PLANT MANUFACTURERS IN HYDERABAD

These ions, such as calcium, magnesium, sodium, and chloride, are typically found in natural water sources. Removing these ions is important for many industrial processes because they can cause scaling, corrosion, and other problems.

Advanced Ion Exchange Regeneration

Our DM plants feature both co-current and counter-current regeneration to optimize resin efficiency and lifespan. The use of strong acid cation and strong base anion resins ensures consistently high water purity. Whether your operation is batch or continuous, these advanced regeneration methods accommodate various industrial requirements and guarantee optimal operational results.

Customizable Design & Flexible Operation

With customizable volumes and capacities from 500 LPH to 100,000 LPH, our DM plants can be tailored to fit any industrial scale. Multiple operation modes (automatic/semi-automatic) and design options (skid-mounted, containerized, or on-site) ensure easy installation and integration with existing processes. Control options range from manual to advanced PLC systems.

Superior Material Quality and Corrosion Resistance

Constructed using premium FRP, MS with FRP lining, or Stainless Steel, our systems are coated with Epoxy/PU for enhanced corrosion protection. These durable materials ensure long service life and minimize maintenance, even under harsh industrial conditions. The robust build guarantees reliable performance and longevity.

FAQs of DM PLANT MANUFACTURERS IN HYDERABAD:

Q: How does the DM plant regeneration process work?

A: Our DM plants use co-current or counter-current regeneration methods, where strong acid cation and strong base anion resins are regenerated with appropriate chemicals. This ensures maximum ion removal efficiency while prolonging resin lifespan, resulting in consistent production of high-purity demineralized water.

Q: What are the main benefits of installing a DM plant from your Hyderabad facility?

A: Installing our DM plant brings several advantages: ultra-low TDS (<1 ppm), effective silica removal (<0.01 ppm), customizable flow rates, robust corrosion-resistant design, low noise operation (<70 dB), high efficiency (up to 98%), and compliance with ISO 9001:2015 standards. It is suitable for various applications like boiler feed, laboratories, pharmaceuticals, and chemical processing.

Q: When should I consider regenerating or replacing the ion exchange resin?

A: Typically, the resins service life is 23 years, depending on water quality and usage patterns. Regeneration is triggered when the treated waters quality drops (e.g., TDS rises or silica appears). Regular monitoring and timely regeneration/replacement maintain optimal plant performance.

Q: Where can the DM plant be installed and used?

A: Our DM plants can be installed on-site, as skid-mounted or containerized units, suitable for industries such as power plants, pharma, labs, and chemical manufacturing. They effectively treat water from different sources including borewell, municipal, ground, or process water.

Q: What pre-filtration is required for your DM plants?

A: A pre-filtration systemusually a sand filter or activated carbon filteris necessary to remove suspended particles and organic matter, protecting the ion exchange resins and ensuring optimal performance and longevity of the DM plant.

Q: How is the water quality monitored throughout the process?

A: Sample valves are provided at key points, allowing for direct water quality checks. The systems PLC-based or manual controls help monitor parameters like conductivity (water out: <0.1 S/cm), ensuring output meets stringent purity requirements.
